-25℃ 12hp Low Temp Scroll Water Cooled Chiller Manufacturer

The HL-12WL model scroll type water cooled chiller units cooling capacity are 8kW.

  • Model :

    HL-12WL
  • Cooling Capacity :

    8kw
  • Input Power :

    10.1kw
  • Refrigerant Type :

    R22 , R134a , R407c , 404a, 410a
  • Compressor Power :

    9Kw
  • Pump Power :

    1.5Kw

The low temperature scroll compressor chiller of Hengde is applicable to products requiring fast temperature reduction, like in the chemical, biological, pharmaceutical, freeze drying, food, and military related industries. Its compressors and principal refrigeration components are all of international renowned brands.  Hengde HL-12W low temperature water type scroll chiller can attain a minimum temperature of -25℃.



Low Temperature Water Chiller



-25℃ 12hp Water cooled Chiller Features:

(1). Famous brand electricity and other spare parts.

(2). The refrigerant can be made to order according to the customer's real situation.

(3). Power supply with customization.

(4). This series of chillers can have acid and alkali resistant cold water machines customized.

(5). An industrial design makes it elegant and ergonomic.

(6). Equipped with a precision temperature controller for laying, it can accurately control the water temperature.

(7). The compressors of the units are of imported brands, namely French Maneurop, American Copeland/Carrier, and German Bitzer, which are medium and low temperature compressors.



Model And Technical Parameter:

Model Unit HL-12WL Low Temp Scroll Water Cooled Chiller Manufacturer
Cooling Capacity Kcal/h 50hz  6880
60hz  8256
Kw 50hz  8
60hz  9.6
Input Power Kw    10.1
Power Supply      3 phs, 380V, 50hz. (Can be customized)
Refrigerant Type    R22, R134a, R407c, 404a, 410a
Control Mode    Outside the balanced thermal expansion valve
Compressor Type    Fully enclosed vortex type (Piston)
Power Kw  9
Condenser Type    Shell and Tube
Cooling Water Flow m³/h  7.9 / 9.48
Pipe Diameter Inch  1-1/2''
Evaporator Type    Shell and Tube / Stainless Steel Plate
Water Flow m³/h  3.69 / 4.64
Pipe Diameter Inch  1-1/2''
Pump Power Kw  1.5
Maximum Head M  20
Safety Protection





 Compressor Overheating、Over Current、High and Low Pressure 、Over Temperature、Traffic、Phase Sequence / Phase Loss Protection、Exhaust Overheating Protection



Our Advantages:

1 - The Factory We Own

  • Specializing in water mold temperature controller and oil mold temperature controller design, production and sales more than 10 years, with area of 15000sqm,over 150 employees.
  • The engineering team has an average of 15 years of experience in industrial refrigeration. The sales team has an average of 8 years of experience in the field..
  • We always provide customized solutions according to specific requirements. Our quality control process consists of three steps: incoming quality control, process quality control, and outgoing quality control. All products come with a 12-month warranty. During the warranty period, if any problem is caused by defects in the mold temperature controller itself, we will offer services until the problem is resolved.



2 - The Partners we cooperate.

Nanjing Hengde Electrical Equipment Co., Ltd



3 - The Glowing Reviews from Numerous Customers.

Nanjing Hengde Electrical Equipment Co., Ltd



4 - The Abundant Industry Cases We Present.

Nanjing Hengde Electrical Equipment Co., Ltd
